D27300 TLOUŠŤKOVAČKA Type 1 | Výkresy
Dokumenty
Seznam náhradních dílů
Zobrazte si rozevírací nabídku, pro některé výrobky může být k dispozici více výkresů
Verze pro tisk
Zobrazit celou stránku
| Položka č. | Číslo výrobku | Množství na | Popis výrobku | General Description | Další info | Trhy | Stav výrobku | Směrná cena |
|---|---|---|---|---|---|---|---|---|
| 1 | 860084-07 | 6 | ŠROUB | 3.2 x 32 | QS |  |
13.00 CZK | |
| 2 | 868852-01 | 1 | KRYT | QS | |
106.60 CZK | ||
| 3 | 868850-00 | 2 | STŮL | QS | |
2581.80 CZK | ||
| 4 | 868855-00 | 4 | DESKA | QS | |
174.20 CZK | ||
| 5 | 860428-07 | 4 | ŠROUB | 3.2 x 32 | QS | |
13.00 CZK | |
| 6 | 868911-00 | 4 | ŠROUB | M6 x 12 | QS | |
13.00 CZK | |
| 7 | 860074-03 | 12 | PODLOŽKA | QS | |
13.00 CZK | ||
| 8 | 868883-00 | 8 | SCREW.SPECIAL | M8 x 12 Torx | QS | |
13.00 CZK | |
| 9 | 860083-04 | 10 | MATICE | QS | |
13.00 CZK | ||
| 10 | 861475-00 | 2 | LOŽISKO | QS | |
70.20 CZK | ||
| 11 | 760242-00 | 4 | ŠROUB | M8 x 30 | QS | |
20.80 CZK | |
| 12 | 860074-02 | 2 | PODLOŽKA | QS | |
13.00 CZK | ||
| 13 | 868859-00 | 1 | PODPĚRA | QS | |
291.20 CZK | ||
| 14 | 868851-01 | 2 | KRYT | QS | |
70.20 CZK | ||
| 15 | 868860-00 | 1 | PODPĚRA | QS | |
291.20 CZK | ||
| 16 | 868816-00 | 1 | LEVÝ RÁM | QS | |
2392.00 CZK | ||
| 17 | 860092-00 | 2 | MATICE | QS | |
13.00 CZK | ||
| 18 | 720959-00 | 6 | PODLOŽKA | QS | |
13.00 CZK | ||
| 19 | 860083-03 | 2 | MATICE | QS | |
13.00 CZK | ||
| 20 | 942895-06 | 1 | OVLADAČ | M6 x 32 | QS | |
20.80 CZK | |
| 21 | 865910-00 | 1 | PODPĚRA | QS | |
174.20 CZK | ||
| 22 | 865909-00 | 1 | KRYT | QS | |
215.80 CZK | ||
| 23 | 860301-13 | 1 | ŠROUB | QS | |
13.00 CZK | ||
| 24 | 860205-04 | 1 | ŠROUB | QS | |
13.00 CZK | ||
| 25 | 868843-00 | 1 | TRUBKA | QS | |
215.80 CZK | ||
| 26 | 860205-07 | 2 | ŠROUB | M6 x 15 | QS | |
13.00 CZK | |
| 27 | 868842-00 | 1 | TRUBKA | QS | |
215.80 CZK | ||
| 28 | 861841-03 | 1 | PÁKA | QS | |
91.00 CZK | ||
| 29 | 860094-02 | 1 | ŠROUB | QS | |
13.00 CZK | ||
| 30 | 868874-00 | 1 | REJSTŘÍK | QS | |
70.20 CZK | ||
| 31 | 868854-00 | 1 | PODPĚRA | QS | |
452.40 CZK | ||
| 32 | 868856-00 | 2 | VODÍTKO | QS | |
252.20 CZK | ||
| 33 | 860658-01 | 1 | PODLOŽKA | QS | |
13.00 CZK | ||
| 34 | 868873-00 | 1 | MĚŘÍTKO | QS | |
57.20 CZK | ||
| 35 | 868857-00 | 1 | TYČ | QS | |
291.20 CZK | ||
| 36 | 868852-00 | 1 | KRYT | QS | |
106.60 CZK | ||
| 37 | 868885-00 | 1 | MATICE | RING | QS | |
106.60 CZK | |
| 38 | 868858-00 | 1 | OVLADAČ | QS | |
174.20 CZK | ||
| 39 | 868876-01 | 1 | KRYT | QS | |
26.00 CZK | ||
| 40 | 868853-00 | 1 | PODPĚRA | QS | |
509.60 CZK | ||
| 41 | 868811-00 | 1 | BOK | QS | |
2392.00 CZK | ||
| 42 | 868849-00 | 1 | PRAVÍTKO | QS | |
1294.80 CZK | ||
| 43 | 868876-00 | 1 | KRYT | QS | |
26.00 CZK | ||
| 44 | 860301-01 | 1 | ŠROUB | QS | |
20.80 CZK | ||
| 45 | 868841-00 | 1 | PŘÍRUBA | QS | |
751.40 CZK | ||
| 46 | 868887-00 | 1 | KRYT | QS | |
26.00 CZK | ||
| 47 | 860094-03 | 1 | ŠROUB | QS | |
13.00 CZK | ||
| 48 | 860093-11 | 2 | ŠROUB | QS | |
13.00 CZK | ||
| 49 | 860092-01 | 3 | MATICE | QS | |
13.00 CZK | ||
| 50 | 941602-00 | 3 | PODLOŽKA | QS | |
13.00 CZK | ||
| 51 | 868846-00 | 1 | HŘÍDEL | QS | |
140.40 CZK | ||
| 52 | 868844-00 | 1 | SKLUZ | QS | |
215.80 CZK | ||
| 53 | 861840-03 | 2 | PÁKA | QS | |
83.20 CZK | ||
| 54 | 868847-00 | 1 | DISTANČNÍ VLOŽKA | QS | |
127.40 CZK | ||
| 55 | 760219-00 | 4 | ŠROUB | QS | |
13.00 CZK | ||
| 56 | 868845-01 | 1 | ÚHELNÍK | QS | |
106.60 CZK | ||
| 57 | 868848-00 | 2 | DESKA | QS | |
140.40 CZK | ||
| 58 | 868845-00 | 1 | 1BLOCK | QS | |
91.00 CZK | ||
| 59 | 860085-09 | 1 | SCREW.TEMP | QS |  |
13.00 CZK | ||
| 60 | 860083-12 | 2 | NUT M6 | QS | |
13.00 CZK | ||
| 61 | 868910-00 | 1 | ŠROUB | QS | |
20.80 CZK | ||
| 62 | 868882-00 | 1 | ŠTÍTEK | QS | |
26.00 CZK | ||
| 63 | 860093-08 | 1 | ŠROUB | QS | |
13.00 CZK | ||
| 64 | 860092-03 | 1 | NUT M5 | QS | |
13.00 CZK | ||
| 65 | 868867-00 | 1 | ODVADĚČ PRACHU | QS | |
452.40 CZK | ||
| 66 | 868824-00 | 1 | VÝROBNÍ ŠTÍTEK | QS | |
57.20 CZK | ||
| 67 | 868822-00 | 2 | TYČ | QS | |
408.20 CZK | ||
| 68 | 868862-01 | 1 | KRYT | QS | |
252.20 CZK | ||
| 69 | 860094-06 | 4 | ŠROUB | QS | |
13.00 CZK | ||
| 70 | 860083-14 | 4 | MATICE | QS | |
13.00 CZK | ||
| 71 | 860078-02 | 4 | PODLOŽKA | QS | |
13.00 CZK | ||
| 72 | 941614-00 | 4 | NOHA | QS | |
41.60 CZK | ||
| 73 | 860073-03 | 14 | WASHER M8 | QS | |
13.00 CZK | ||
| 74 | 949886-16 | 8 | ŠROUB | QS | |
13.00 CZK | ||
| 75 | 861073-00 | 4 | NOHA | QS | |
174.20 CZK | ||
| 76 | 868864-00 | 4 | NOHA | QS | |
366.60 CZK | ||
| 77 | 941756-00 | 4 | OVLADAČ | QS | |
36.40 CZK | ||
| 78 | 860301-18 | 4 | ŠROUB | M8 x 45 | QS | |
20.80 CZK | |
| 79 | 860085-29 | 2 | ŠROUB | QS | |
20.80 CZK | ||
| 80 | 868875-00 | 1 | PODPĚRA KOTOUČE | QS | |
291.20 CZK | ||
| 81 | 868866-00 | 2 | NÁPRAVA | QS | |
106.60 CZK | ||
| 82 | 868865-00 | 2 | KOTOUČ | QS | |
83.20 CZK | ||
| 83 | 868875-01 | 1 | PODPĚRA KOTOUČE | QS | |
127.40 CZK | ||
| 84 | 868871-00 | 1 | MĚŘÍTKO | QS | |
83.20 CZK | ||
| 85 | 760271-01 | 4 | ŠROUB | QS | |
13.00 CZK | ||
| 86 | 868823-00 | 1 | DESKA | QS | |
106.60 CZK | ||
| 87 | 868863-00 | 1 | VÝROBNÍ ŠTÍTEK | QS | |
62.40 CZK | ||
| 89 | 860074-03 | 4 | PODLOŽKA | QS | |
13.00 CZK | ||
| 90 | 860083-04 | 4 | MATICE | QS | |
13.00 CZK | ||
| 91 | 868835-00 | 1 | ZÁVRTNÝ ŠROUB | QS | |
174.20 CZK | ||
| 92 | 932302-00 | 4 | PODLOŽKA | QS | |
13.00 CZK | ||
| 93 | 123219-00 | 2 | POUZDRO | QS | |
106.60 CZK | ||
| 94 | 123316-01 | 1 | ŘEMENICE | QS | |
252.20 CZK | ||
| 95 | 860079-02 | 2 | POJISTNÝ KROUŽEK | QS | |
13.00 CZK | ||
| 96 | 868830-01 | 1 | ŘETĚZ | QS | |
106.60 CZK | ||
| 97 | 868755-00 | 1 | PRUŽINA | QS | |
31.20 CZK | ||
| 98 | 860753-00 | 1 | NAPÍNÁK ŘETĚZU | QS | |
291.20 CZK | ||
| 99 | 869468-00 | 2 | PÁR ŘEZNÝCH NÁSTROJŮ | QS | ||||
| 100 | 868870-00 | 1 | KOTOUČ | QS | |
291.20 CZK | ||
| 101 | 868834-00 | 1 | ZÁVRTNÝ ŠROUB | QS | |
140.40 CZK | ||
| 102 | 868833-00 | 1 | DESKA | QS | |
140.40 CZK | ||
| 103 | 941602-00 | 2 | PODLOŽKA | QS | |
13.00 CZK | ||
| 104 | 860083-04 | 2 | MATICE | QS | |
13.00 CZK | ||
| 105 | 868838-00 | 1 | ŘEMEN | QS | |
332.80 CZK | ||
| 106 | 868837-00 | 1 | ŘEMEN | QS | |
452.40 CZK | ||
| 107 | 932293-00 | 1 | PODLOŽKA | QS | |
20.80 CZK | ||
| 108 | 860155-08 | 2 | LOŽISKO | QS | |
215.80 CZK | ||
| 109 | 865526-01 | 2 | KLÍN SA | QS | |
1245.40 CZK | ||
| 110 | 949703-10 | 8 | ŠROUB | QS | |
36.40 CZK | ||
| 111 | 863644-00 | 4 | ŠROUB | QS | |
70.20 CZK | ||
| 112 | 868892-00 | 1 | FRÉZOVACÍ BLOK SA | QS | ||||
| 113 | 860093-15 | 2 | ŠROUB | QS | |
13.00 CZK | ||
| 114 | 863658-00 | 4 | BLOK | QS | |
41.60 CZK | ||
| 115 | 123232-00 | 2 | PRUŽINA | QS | |
31.20 CZK | ||
| 116 | 942043-00 | 4 | ŠROUB | QS | |
20.80 CZK | ||
| 117 | 860074-03 | 4 | PODLOŽKA | QS | |
13.00 CZK | ||
| 118 | 941563-00 | 4 | MATICE | QS | |
26.00 CZK | ||
| 119 | 860226-02 | 4 | PODLOŽKA | QS | |
13.00 CZK | ||
| 120 | 868868-00 | 1 | VÁLEC | QS | |
800.80 CZK | ||
| 121 | 868869-00 | 1 | VÁLEC | QS | |
751.40 CZK | ||
| 122 | 860282-03 | 2 | OZUBENÉ KOLO | QS | |
91.00 CZK | ||
| 123 | 868884-00 | 32 | ZAŘÍZENÍ PROTI ZPĚTNÉMU RÁZU | QS | |
20.80 CZK | ||
| 124 | 860073-05 | 51 | PODLOŽKA | QS | |
13.00 CZK | ||
| 125 | 868819-00 | 1 | TYČ | QS | |
291.20 CZK | ||
| 126 | 868818-00 | 1 | TYČ | QS | |
332.80 CZK | ||
| 127 | 123233-00 | 2 | PRUŽINA | QS | |
31.20 CZK | ||
| 128 | 949886-16 | 2 | ŠROUB | QS | |
13.00 CZK | ||
| 129 | 932285-00 | 1 | PODLOŽKA | QS | |
70.20 CZK | ||
| 130 | 949751-07 | 1 | SPANNER 10-13MM | QS | |
57.20 CZK | ||
| 131 | 943271-00 | 1 | HEX KEY 2.5 MM | QS | |
13.00 CZK | ||
| 132 | 949882-01 | 1 | WRENCH 4 MM | QS | |
20.80 CZK | ||
| 133 | 930574-00 | 1 | HEX KEY 5 MM | QS | |
20.80 CZK | ||
| 134 | 860098-04 | 1 | WRENCH 6 MM | QS | |
20.80 CZK | ||
| 135 | 860610-01 | 1 | TLAČNÁ TYČ | QS | |
106.60 CZK | ||
| 136 | 863648-00 | 1 | UKAZATEL | QS | |
52.00 CZK | ||
| 137 | 868820-00 | 1 | TYČOVÝ PLOT | QS | |
106.60 CZK | ||
| 138 | 868828-00 | 4 | VÁLEC | QS | |
252.20 CZK | ||
| 139 | 860083-14 | 4 | MATICE | QS | |
13.00 CZK | ||
| 140 | 860085-13 | 8 | ŠROUB | QS | |
13.00 CZK | ||
| 141 | 868886-00 | 2 | KRYT | QS | |
36.40 CZK | ||
| 142 | 868827-00 | 2 | KONZOLA | QS | |
366.60 CZK | ||
| 143 | 868829-00 | 2 | KONZOLA | QS | |
127.40 CZK | ||
| 144 | 868814-00 | 4 | PODPĚRA | QS | |
174.20 CZK | ||
| 145 | 860093-14 | 4 | ŠROUB | QS | |
13.00 CZK | ||
| 146 | 860083-04 | 12 | MATICE | QS | |
13.00 CZK | ||
| 147 | 941602-00 | 4 | PODLOŽKA | QS | |
13.00 CZK | ||
| 148 | 868861-00 | 2 | DESKA | QS | |
36.40 CZK | ||
| 149 | 860085-29 | 4 | ŠROUB | QS | |
20.80 CZK | ||
| 150 | 949876-19 | 4 | PODLOŽKA | QS | |
13.00 CZK | ||
| 151 | 868821-00 | 1 | HANDLE | QS | |
252.20 CZK | ||
| 152 | 860092-06 | 1 | MATICE | QS | |
13.00 CZK | ||
| 153 | 860096-07 | 1 | ZÁVLAČKA | QS | |
13.00 CZK | ||
| 154 | 868817-00 | 1 | VŘETENO | QS | |
252.20 CZK | ||
| 155 | 860282-02 | 4 | PASTOREK | QS | |
70.20 CZK | ||
| 156 | 868812-00 | 3 | VŘETENO | QS | |
215.80 CZK | ||
| 157 | 911392-00 | 5 | POJISTNÝ KROUŽEK | QS | |
13.00 CZK | ||
| 158 | 868830-00 | 1 | ŘETĚZ | QS | |
215.80 CZK | ||
| 159 | 868813-00 | 1 | KOLÍK | QS | |
70.20 CZK | ||
| 160 | 943023-00 | 1 | ŠROUB | QS | |
13.00 CZK | ||
| 161 | 868872-00 | 1 | UKAZATEL | QS | |
70.20 CZK | ||
| 162 | 860074-03 | 12 | PODLOŽKA | QS | |
13.00 CZK | ||
| 163 | 868881-00 | 1 | HANDLE | QS | |
156.00 CZK | ||
| 164 | 865774-00 | 1 | PASTOREK | QS | |
127.40 CZK | ||
| 165 | 860075-00 | 1 | PODLOŽKA | QS | |
13.00 CZK | ||
| 166 | 860083-12 | 1 | NUT M6 | QS | |
13.00 CZK | ||
| 167 | 868825-00 | 1 | STŮL | QS | |
3595.80 CZK | ||
| 168 | 860085-27 | 4 | ŠROUB | QS | |
20.80 CZK | ||
| 169 | 860092-00 | 1 | MATICE | QS | |
13.00 CZK | ||
| 170 | 861475-00 | 3 | LOŽISKO | QS | |
70.20 CZK | ||
| 171 | 860286-00 | 3 | PODLOŽKA | QS | |
31.20 CZK | ||
| 172 | 932227-00 | 1 | LOŽISKO | QS | |
140.40 CZK | ||
| 173 | 868815-00 | 1 | PODLOŽKA | QS | |
31.20 CZK | ||
| 174 | 931892-00 | 3 | PODLOŽKA | QS | |
13.00 CZK | ||
| 175 | 932302-00 | 1 | PODLOŽKA | QS | |
13.00 CZK | ||
| 176 | 949743-02 | 4 | ŠROUB | M8 x 14mm | QS | |
20.80 CZK | |
| 177 | 860092-01 | 3 | MATICE | QS | |
13.00 CZK | ||
| 178 | 868880-00 | 1 | SPÍNACÍ SKŘÍŇKA | QS | |
1833.00 CZK | ||
| 179 | 868913-00 | 1 | COVERPLATE 3PH | 3 Ph - XS | QS | |
62.40 CZK | |
| 180 | 868242-03 | 1 | KONTAKT | QS | |
702.00 CZK | ||
| 181 | 868878-00 | 1 | OCHRANA PROTI PŘETÍŽENÍ | 1Ph | QS | |
1747.20 CZK | |
| 181 | 868878-01 | 1 | OCHRANA PROTI PŘETÍŽENÍ 3 FÁZE | 3 Ph - XS | QS | |
1245.40 CZK | |
| 182 | 860084-21 | 2 | ŠROUB | QS | |
13.00 CZK | ||
| 183 | 868877-01 | 1 | MOTOR CABLE 3 PHASE | 3Ph | QS | |
408.20 CZK | |
| 183 | 868877-00 | 1 | KABEL MOTORU | QS | |
408.20 CZK | ||
| 184 | 868879-00 | 1 | CABLE 1 PH | QS | |
751.40 CZK | ||
| 185 | 868810-00 | 1 | SPÍNACÍ SKŘÍŇKA A KABEL | QS | |
2581.80 CZK | ||
| 185 | 868810-02 | 1 | SWITCHBOX & CABLE 3 PHASE | 3 PHASE | QS | |
4149.60 CZK | |
| 186 | 868802-00 | 1 | VŘETENO | QS | |
509.60 CZK | ||
| 187 | 860155-08 | 1 | LOŽISKO | QS | |
215.80 CZK | ||
| 188 | 868425-07 | 1 | ROTOR | QS | |
1638.00 CZK | ||
| 189 | 868541-06 | 1 | STATOR SA 230V | QS | |
4555.20 CZK | ||
| 190 | 861721-00 | 1 | LOŽISKO | QS | |
70.20 CZK | ||
| 191 | 860080-00 | 1 | KROUŽEK | QS | |
13.00 CZK | ||
| 192 | 868801-00 | 1 | KRYT | QS | |
252.20 CZK | ||
| 193 | 860446-02 | 4 | ŠROUB | QS | |
20.80 CZK | ||
| 194 | 861718-00 | 1 | VENTILÁTOR | QS | |
52.00 CZK | ||
| 195 | 868805-00 | 1 | KONCOVÁ KRYTKA | QS | |
83.20 CZK | ||
| 196 | 868807-00 | 1 | KRABICE | QS | |
127.40 CZK | ||
| 197 | 860084-04 | 7 | ŠROUB | QS | |
13.00 CZK | ||
| 198 | 949772-50 | 1 | KONDENZÁTOR | 30uF | QS | |
291.20 CZK | |
| 199 | 860468-02 | 1 | SPOJKA | QS | |
70.20 CZK | ||
| 200 | 868809-00 | 1 | SVORKA | QS | |
13.00 CZK | ||
| 201 | 868808-00 | 1 | SVORKA | QS | |
20.80 CZK | ||
| 202 | 860094-02 | 5 | ŠROUB | QS | |
13.00 CZK | ||
| 203 | 868806-00 | 1 | TĚSNĚNÍ | QS | |
36.40 CZK | ||
| 204 | 868387-15 | 1 | MOTOR 230V | QS | |
8512.40 CZK | ||
| 204 | 868387-16 | 1 | MOTOR 3 PH | XS | QS | |
9981.40 CZK | |
| 205 | 860539-01 | 1 | KLÍČ | QS | |
20.80 CZK | ||
| 206 | 861068-00 | 2 | PODLOŽKA | QS | |
26.00 CZK | ||
| 207 | 868832-00 | 1 | ŘEMENICE | QS | |
291.20 CZK | ||
| 208 | 861983-01 | 1 | PODLOŽKA | QS | |
20.80 CZK | ||
| 209 | 860093-15 | 1 | ŠROUB | QS | |
13.00 CZK | ||
| 210 | 945848-00 | 1 | SPONKA | QS | |
20.80 CZK | ||
| 211 | 868831-00 | 1 | TĚSNICÍ KROUŽEK | QS | |
26.00 CZK | ||
| 212 | 949876-19 | 2 | PODLOŽKA | QS | |
13.00 CZK | ||
| 213 | 860093-07 | 2 | ŠROUB | QS | |
13.00 CZK | ||
| 214 | 860094-03 | 5 | ŠROUB | QS | |
13.00 CZK | ||
| 215 | 868879-02 | 1 | CABLE 3 PH | 3Ph - XS | QS | |
702.00 CZK | |
| 216 | 860637-00 | 1 | ZÁSTRČKA 3 FÁZE | QS | |
252.20 CZK | ||
| 217 | 868879-04 | 1 | CABLE & PLUG 3 PHASE | XS | QS | |
902.20 CZK | |
| 218 | 946085-00 | 1 | SPOJKA | QS | |
127.40 CZK | ||
| 219 | 933652-00 | 1 | PODLOŽKA | QS | |
13.00 CZK | ||
| 220 | 868806-02 | 1 | TĚSNĚNÍ | QS | |
36.40 CZK | ||
| 221 | 868922-00 | 1 | ŠTÍTEK | QS | |
26.00 CZK | ||
| 222 | 868921-00 | 1 | ŠTÍTEK | QS | |
31.20 CZK |
* Jedná se o orientační ceny, které se mohou lišit a jsou uvedeny bez DPH a náklady na dopravu.Vyhrazujeme si právo na změnu cen a podmínek bez předchozího upozornění.
