DW705 | MITRE SAW Type 7
General Details
| Type Identifier | 7 |
| Status | Discontinued |
| Repair Instruction Status | Repair |
| Last Date of Manufacture |
Change your location Ecuador, Latin America
Filter your results
Quick spare parts search
Enter part number or name.
Step by step
Search for your tool step by step.
Catalogue search
Browse our catalogue
Parts List
Technical specifications
| TECH Attribute | Value | Unit | Code |
|---|---|---|---|
| Frequency | 50/60 | Hz | |
| Nameplate Amps | 15.0 | A | |
| Nameplate Speed | 4000 | RPM | |
| Nameplate Voltage | 120 | Vac | |
| Nameplate Watts | 1375 | W | |
| No Load Current (Min) | 6.0 | A | |
| No Load Current (Max) | 7.3 | A | |
| No Load Speed (Min) | 3800 | RPM | |
| No Load Speed (Max) | 4200 | RPM |
