FSMH16151 STEAM MOP Type 1 | Drawings
Documents
Parts List
Save PDF
View Full Page
| Item No. | Product Number | Qty Per | Product Description | General Description | Other Info | Markets | Product Status |
|---|---|---|---|---|---|---|---|
| 1 | 90578577 | 1 | HEAD SA | FSMH1621D | B5 |  |
|
| 1 | 90575387-01 | 1 | PARQUET FLOOR HEAD | RED | FSMH1621 | B5 | |
| 2 | 90585491 | 1 | TOOL CARPET | B5 | |
||
| 3 | 90590822 | 1 | STAND | B5 | |
||
| 4 | 90592275SV | 1 | LID SA | B5 |  |
||
| 5 | 90583080 | 1 | SWITCH | B5 | |
||
| 6 | 90584671 | 1 | SWITCH & PCB | B5 | |
||
| 7 | 90584900 | 1 | TRIGGER | B5 | |
||
| 8 | 90588529 | 1 | COVER HOUSING | Blue - Aqua | B5 | |
|
| 10 | 90595819 | 1 | HEAD SA | SCENTED | FSMH1621S | B5 | |
| 12 | 90577995 | 1 | PCB SA | B5 | |
||
| 15 | 90589659 | 1 | VALVE | B5 | |
||
| 18 | 90586469 | 1 | NOZZLE | B5 | |
||
| 20 | 90584673 | 1 | CONTROL PANEL | B5 | |
||
| 21 | 90580120-00 | 1 | HOOK | B5 | |
||
| 22 | 90581159 | 1 | LEVER | B5 | |
||
| 25 | 90585863 | 2 | O RING | B5 | |||
| 31 | 90586093-06 | 1 | BRUSH | GREEN | Green | B5 | |
| 31 | 90586093-06 | 1 | BRUSH | GREEN | Green | B5 | |
| 31 | 90586093-07 | 1 | BRUSH | Yellow | B5 | |
|
| 31 | 90586093-05 | 1 | BRUSH | Blue | B5 | |
|
| 32 | 90586133 | 1 | NOZZLE | B5 | |
||
| 33 | 90586489 | 1 | HOLDER,RUBBER | Small | B5 | |
|
| 34 | N524612 | 1 | HOSE SA | B5 | |
||
| 35 | 5146986-00 | 1 | BAG | B5 | |
||
| 36 | 90587424 | 1 | CONTAINER | B5 | |
||
| 39 | 90588389-01 | 1 | TOOL BRUSH | WIRE | B5 | |
|
| 40 | 90580871 | 1 | HANDLE SA | B5 | |
||
| 60 | 90585121 | 1 | PUMP SA | B5 | |
||
| 61 | 90587265 | 1 | CLIP | B5 | |
||
| 62 | 90618866-02 | 1 | PIPE | B5 | |
||
| 100 | 90585868 | 1 | PAD SA | B5 | |
||
| 101 | 90586861 | 1 | CLEANING PAD | FSMH1621D | B5 | |
