BPSP125 TILE CUTTER Type 1 | Drawings
Documents
Parts List
Save PDF
View Full Page
| Item No. | Product Number | Qty Per | Product Description | General Description | Other Info | Markets | Product Status |
|---|---|---|---|---|---|---|---|
| 1 | 49202004 | 1 | SCREW | 7*16 | A9 | ||
| 2 | 4240204015 | 1 | OUTER FLANGE | A9 | |||
| 3 | 4240204011 | 1 | INNER FLANGE | A9 | |||
| 4 | NA042557 | 1 | SPINDLE | A9 | |||
| 5 | 49203037 | 2 | SCREW | 5*25 | A9 | ||
| 6 | 4240202009 | 1 | BEARING BLOCK | A9 | |||
| 7 | 4240203003 | 1 | SEAL | A9 | |||
| 8 | 4140704002 | 1 | WASHER | 12 x 26.5 x 0.2 mm; 12*26.5*0.2 | A9 | ||
| 9 | 49109012 | 1 | BEARING | A9 | |||
| 10 | 49207027 | 1 | CIRCLIP | A9 | |||
| 11 | 4240204009 | 1 | RING | A9 | |||
| 12 | 4240202008 | 1 | COVER BEARING | A9 | |||
| 13 | 49208003 | 1 | LOCK PIN | A9 | |||
| 14 | 4240610601 | 1 | GEAR | A9 | |||
| 15 | 4240204004 | 1 | COTTER PIN | A9 | |||
| 16 | 4090104007 | 1 | GASKET | A9 | |||
| 17 | 4240204005 | 1 | SHOE | A9 | |||
| 18 | 4240204002 | 1 | SLEEVE | A9 | |||
| 19 | 4240201002 | 1 | SCREW | A9 | |||
| 23 | 4240610602 | 1 | PINION | A9 | |||
| 24 | 4090104003 | 1 | WASHER | 8 x 15 x 0.2 mm; 8*15*0.2 | A9 | ||
| 25 | 49109017 | 1 | BEARING | A9 | |||
| 26 | 4240203007 | 1 | RUBBER SEAL | A9 | |||
| 27 | 4240204008 | 1 | WASHER | A9 | |||
| 28 | 49208001 | 1 | WOODRUFF KEY | A9 | |||
| 30 | 494005 | 1 | CAPACITOR | A9 | |||
| 31 | 49206018 | 2 | SCREW | SELF-TAPPING 4*15 | A9 | ||
| 32 | 4240601604 | 1 | CORD CLAMP | A9 | |||
| 33 | 49303005 | 1 | CORD PROTECTOR | A9 | |||
| 34 | Z49306013 | 1 | CORDSET | A9 | |||
| 35 | 4240206002 | 1 | BRUSH PAIR | A9 | |||
| 36 | N535231 | 1 | BRUSH & HOLDER SA | A9 | |||
| 37 | 4240601605 | 1 | BAFFLE | A9 | |||
| 38 | 49206040 | 2 | SCREW | self-tapping 5*65 | A9 | ||
| 39 | Z60324015 | 1 | FIELD SA | A9 | |||
| 40 | 4240601606 | 1 | WASHER INSULATING | A9 | |||
| 41 | 49111013 | 1 | BEARING | A9 | |||
| 42 | 4240204001 | 1 | WASHER | A9 | |||
| 43 | 4240203001 | 1 | O RING | A9 | |||
| 44 | 4240203004 | 1 | NUT | A9 | |||
| 45 | 4240601701 | 1 | HANDLE COVER | A9 | |||
| 46 | 4240603601 | 1 | BOOT | A9 | |||
| 47 | 4240205601 | 1 | SWITCH | A9 | |||
| 48 | 4240203002 | 1 | COLUMN | A9 | |||
| 49 | 4240621701 | 1 | RATING LABEL | A9 | |||
| 50 | 49206020 | 4 | SCREW | self-tapping 4*18; self-tapping 4x18 mm | A9 | ||
| 51 | 4240204010 | 1 | SPANNER | A9 | |||
| 52 | 4240204014 | 1 | HEX KEY | A9 | |||
| 53 | 49203036 | 3 | SCREW | 5*23 | A9 | ||
| 54 | 4240601703 | 1 | HOUSING SA | A9 | |||
| 56 | 4240601702 | 1 | END CAP | A9 | |||
| 57 | 49206016 | 2 | SCREW | self-tapping 4*12; self-tapping 4x12 mm | A9 | ||
| 58 | 4240622701 | 1 | LABEL | A9 | |||
| 300 | 4240650001 | 1 | SPINDLE & GEAR SA | A9 | |||
| 301 | 4240650002 | 1 | GEARCASE SA | A9 | |||
| 302 | 4240650003 | 1 | ARMATURE SA | A9 | |||
| 800 | 901181 | 1 | GREASE | 1kg; specification:1KG | A9 |
